Description

• Frame: FORM™ Alloy | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-4™ Adjustable Geometry | 2 Position Axle | 180mm Travel. FORM™ Alloy Rear Triangle
• Fork: RockShox Boxxer Select RC 200mm | 27.5 = 36mm Offset | 29 = 46mm Offset
• Front Travel: 200
• Shock: RockShox Super Deluxe Coil Select | Sealed Bearing Eyelet | 25x8mm F Hardware | All Sizes = 230 x 65mm | Size-Specific tune in FAQ
• Rear Travel: 180
• Headset: FSA Orbit NO.57E | Sealed 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5″ Crown Race
• Stem: Rocky Mountain 35 CNC DH
• Handlebar: Rocky Mountain AM | 780mm Width | 38mm Rise | 9° Backsweep | 5° Upsweep | 35 Clamp
• Grips: ODI Elite Pro Lock On
• Brakes: Sram Guide RE 4 Piston | Metal Pads | F:Sram Centerline 220mm | R:Sram Centerline 200mm
• Shifters: Sram GX DH
• Rear Derailleur: Sram GX DH
• Cranks & Chainring: Race Face Aeffect R Cinch | 32T | 24mm Spindle | 170mm Crank Length
• Bottom Bracket: Shimano SM-BBMT500
• Cassette: Sram PG-720 11-25T
• Chain: KMC X11-1
• Front Hub: Rocky Mountain Sealed Boost 20mm
• Rear Hub: Sram MTH 746 Boost 148mm
• Spokes: 2.0 Stainless
• Rims: Race Face ARC HD 30 | 32H | Tubeless Compatible – Tape / Valves / Sealant Not Incl
• Tires:
  F: Maxxis Minion DHF 2.5 WT 3C MaxxGrip DH Tubeless Ready // R: Maxxis Minion DHR II 2.4 WT 3C MaxxGrip DH Tubeless Ready
• Seatpost: Rocky Mountain SL 30.9mm
• Saddle: WTB Volt Race 142
