Description
-
- Frame FORM™ Alloy. Full Sealed Cartridge Bearings. Press Fit BB92. Internal Cable Routing. 2-Bolt ISCG05 Tabs. RIDE-4™ Adjustable Geometry + Suspension Rate. 29: 170mm Travel / 27.5: 180mm Travel. FORM™ Alloy Rear Triangle
- Sizes 27.5 = SM – MD | 29 = MD – LG – XL
- Fork Marzocchi Z1 Float EVOL GRIP. 29: 170mm, 44mm Offset| 27.5: 180mm, 44mm Offset
- Front Travel180mm
- Shock Marzocchi Bomber CR | Steel Spring | Sealed Bearing Eyelet | 25x8mm F Hardware | All Sizes = 230x65mm | Size-Specific tune in FAQ
- Rear Travel27.5 – 180mm | 29 – 170mm
- Headset FSA Orbit NO.57E | 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5″ Crown Race
- Stem Rocky Mountain 35 AM | 5° Rise | All Sizes = 40m
- Handlebar Rocky Mountain AM | 780mm Width | 27.5 = 38mm Rise | 29 = 25mm Rise | 9° Backsweep | 5° Upsweep | 35mm Clamp
- Grip sErgon GD10 EVO Lock On
- Brakes Shimano 6120 Trail 4 Piston | Metal Pads | RT64 203mm F Rotor | RT64 203mm R Rotor
- Shifters Shimano Deore 12spd
- Rear Derailleur Shimano Deore 12spd
- Cranks & Chainrings Race Face Ride Cinch | 27.5 = 34T | 29 = 32T | 24mm Spindle | 170mm Crank Length
- Bottom Bracket Shimano SM-BBMT500
- Cassette Shimano Deore 10-51T 12spd
- Chain Shimano M6100
- Front Hub Shimano MT410 | 15mm Boost
- Rear Hub Shimano MT410 Boost 148mm | RMB Axle | 163mm x 12mm x 1.5mm
- Spokes2.0 Stainless
- Rims WTB ST i30 TCS 2.0 Tubeless | Tubeless Ready – Tape | Valves Incl | 32H
- Tires F: Maxxis Minion DHF 2.5 WT 3C Maxx Grip DD Tubeless Ready // R: Maxxis Minion DHR II 2.4 WT 3C Maxx Grip DD Tubeless Ready
- Seat post Rocky Mountain Toonie Drop Alloy 30.9mm | SM = 125mm | MD – LG = 150mm | XL = 170mm
- Saddle WTB Volt Race | Cromoly Rails | 142mm Width
- Weight17.05 KG | 37.5 LBS | Incl. Inner Tubes
